Separation and Compensation Principle in Strikes Animation

There is an important principle which allows for any strike animation to be more believable and powerful. This principle was used to make strikes animation in the Shadow Fight game series. Let’s take a look at how it works on an example of several strikes taken directly from our animators guideline.

A bit of theory

The main contradiction of all strikes is:
The strike phase should be fast and sharp, BUT the trajectory of the center of mass should be always smooth, and the general angular momentum (general rotation) should also change smoothly. Because the center of mass is the most inertial point of the character.

The two main solutions are:

1. Separation:

During the swing, the body and legs accelerate/rotate and accumulate energy. After that, the energy is transferred into the weapon or the attacking limb. The body and legs almost come to a stop BEFORE the fast phase of the strike begins.
We separate strike phases in time. The phases being:

  • Fast strike phase.
  • Slow energy accumulation (before the strike) or attenuation (after the strike) phase.
Separation means that one phase follows another phase. They are NOT simultaneous.

2. Compensation

Simultaneously with the strike, the body and legs move/rotate in the opposite direction and compensate for the sharp movement of the weapon or the attacking limb.

We do NOT separate these actions in time. They happen SIMULTANEOUSLY.

How it works

This principle is most frequently used when combining strikes with steps. Let’s illustrate it with some sword slashes examples.

Inward slash preceded by a step


While swinging, we take a big step forward to gain velocity and rotation speed. The body gets twisted now. After that, we untwist the body and nearly come to a stop to transfer the energy to the weapon and make a slash. This is separation.

Outward slash preceded by a step


Similar to the inward one. This is separation too.
In these two slashes, we take time to make a step, then we make a strong slash.

Inward slash followed by a step


While swinging, we take a small step forward. Then while making a slash we gain velocity and rotation speed. The body gets twisted. Once the weapon nearly comes to a stop, the energy is transferred into a step. This is separation as well.

Outward slash followed by a step


Similar to the inward one. This is separation. In these two slashes, we execute a strong slash, then we take time to make a step.

Inward slash without a step


We may make a small step while swinging, but we make a slash without any step. After that the body gets twisted.

Outward slash without a step


Similar to the inward one. In these two slashes, we neither use separation nor compensation, so they are neither strong nor fast. But the body gets twisted (which is important for combos).

Inward slash with a simultaneous step


If the body is twisted, we can make a slash with a simultaneous step with the opposite leg to compensate for the slash. The body gets twisted in the opposite direction. This is compensation.

Outward slash with a simultaneous step


Similar to the inward one. This is compensation.

These two slashes are fast, but not strong.

Inward spinning slash


While swinging, we take a big step forward to gain velocity and rotation speed. Then we transfer the energy to the weapon and make a strong slash. After that, the energy is transferred into the spin and the step. This is separation.

Outward spinning slash


We make a big step with a back spin to gain velocity and rotation speed. Once the spin is complete, we transfer the energy to the weapon and make a very strong slash. This is separation.

There is a major difference between these slashes:
  • With an inward spinning slash, we make a very strong slash with a step, then we take time to make a step with a spin.
  • With an outward spinning slash, we take time to make a step with a spin, then we make a very strong slash.

This principle can be used to make various strikes: horizontal, diagonal and stabbing ones. It also works with punches and kicks. Further understanding of this principle will allow you to make various continuous combos.
